Adding Inventory Matrix

* Select ADD from the inventory menu and display

add inventory submenu. Select Matrix to add item.

* Add general inventory information from the screen

just as standard items.

* After general information is entered the screen will

change to a box labeled columns and rows. The

general principle for matrix items is to have one

product number with multiple types, sizes or colors

such as garments, shoes, bikes ...

* Enter the column headers you would like across the

top. Entry on a blank column header will move the

cursor to the rows entry fields. Enter these the same

way. Again, entry on a blank row box will move the

cursor to the next step quantity entry. An example

would be SM, MED and LG for columns and RED,

GREEN & BLUE for rows (or vise versa).

* Enter the quantity in each box that corresponds with

the columns and rows. The system will move you

from left to right and from top to bottom.

* Once you have completed an the boxes you will be

prompted for the next inventory matrix item. Con-

tinue just as you would with standard items from here.

* You can not edit matrix column and row names - if

you want to change the names you must delete the item

and re-enter it. You can edit the inventory basic infor-

mation such as price, vendors or quantities at any time.

* If you want to use a number for your matrix rows or

columns you need to use a letter in the field first then

type in the number. An example would be if you

wanted to make a row for size 10 you would put (S10)

for the field name.

Printing Inventory Labels

* Printing inventory labels is a multiple

step process that will ask you several

multiple choice questions.

* First you will need one up labels

(AVERY 4010) and calibrate you printer

for the labels. Press y to start a test

print of three labels. Any key will stop

the process orX will cycle three more

labels.

* Next you will need to select the search

field for the label/s you would like to

print. If you want to print an select the

PRODNO field and enter >0 and press

E.

* Select the operator you would like to use for your search equal, greater or less than.

* Type in the search criteria to meet for the labels to print.

* A tally of the records matching your search criteria will be displayed and you will be prompted if you would like

to continue. Yes y is the default, if you do not want to print the criteria selected selectn or X.

* You will then be asked if you want bar codes generated, select y or n.

* Finally before printing begins you will be asked for the quantity of labels to print. You can select an the labels, one

for each inventory item or just one label per product number.

* You can reprint labels any time you would like.
